Capacity:	1500 mAh
Voltage:	7.4 Volts
Final Charge Voltage:	8.40 Volts
Final Discharge Voltage:	6.20 Volts under load
Power Supply Charge Voltage Input for Intgrated Charger:	10.0 Volts +/- 0.10 Volt
Temp. Range Charging:	32° F to 140° F
Temp. Range Discharging:	32° F to 140° F
Weight Including Wire:	4.00 oz.
Weight of Battery Holder:	0.40 oz.
Dimensions:	3.50" x 1.75" x 0.625"
Length of Cable:	11 in.
Connector Type:	Available with JR or 6 Pin Multiplex Connector
Charger is built into each battery and only weighs a couple of grams Integrated charger means no charging horror stories or battery damage Uses a simple AC adapter to charge ( No expensive chargers to buy or learn how to program and use ) Integrated temperature monitoring prevents battery damage Unique Lithium-Polymer battery chemistry allows high current delivery for giant-scale applications where Typical 'consumer' LiPoly cells can't Exceeds the performance of a 2800 mAh Lithium-Ion by over 25% with a weight savings of 25%! Battery holder design saves money by allowing easy battery exchange between airplanes for only a few dollars per plane Battery case design is nearly indestructable fiber reinforced plastic Holder design is made from Delrin for flexibility and durability. It prevents vibration and protects your investment. Battery holds 95% charge after a year Unique Lithium-Polymer cell chemistry was developed specifically for PowerBox Systems by Ionity AG, Germany

Operating Instructions (Adobe PDF Format 160 KB)

Distributed in the Americas
Exclusively By:
Aircraft International, Inc.
