Capacity:	2800 mAh
Voltage:	7.4 Volts
Final Charge Voltage:	8.40 Volts
Final Discharge Voltage:	6.20 Volts under load
Power Supply Charge Voltage Input for Intgrated Charger:	10.0 Volts +/- 0.10 Volt
Temp. Range Charging:	32° F to 140° F
Temp. Range Discharging:	32° F to 140° F
Weight Including Wire:	5.57 oz.
Weight of Battery Holder:	0.63 oz.
Dimensions:	4.22" x 2.56" x 0.59"
Length of Cable:	11 in.
Connector Type:	Available with JR or 6 Pin Multiplex Connector
Charger is built into each battery and only weighs a couple of grams Integrated charger means no charging horror stories or battery damage Uses a simple AC adapter to charge ( No expensive chargers to buy or learn how to program and use ) Integrated temperature monitoring prevents battery damage Unique Lithium-Polymer battery chemistry allows high current delivery for giant-scale applications where Typical 'consumer' LiPoly cells can't Typical performance on a 40% aerobatic plane with 14 digital servos is approx. 8 - 10 very active (3D) flights, lasting approx. 10 minutes each, with 30% battery capacity remaining Exceeds the performance of a 4000 mAh Lithium-Ion with a weight savings of 25% Battery holder design saves money by allowing easy battery exchange between airplanes for only a few dollars per plane Battery case design is nearly indestructable fiber reinforced plastic Holder design is made from Delrin for flexibility and durability. It prevents vibration and protects your investment. Battery holds 95% charge after a year Unique Lithium-Polymer cell chemistry was developed specifically for PowerBox Systems by Ionity AG, Germany

Operating Instructions (Adobe PDF Format 160 KB)
